In our previous blog, we have seen Elasticsearch is a highly scalable open-source full-text search and analytics engine, built on the top of Apache Lucene. Elasticsearch allows you to store, search, and analyze huge volumes of data as quickly as possible and in near real-time.
ES uses Inverted Indexes under the hood. Inverted Index is an index which maps terms to documents containing them.
Let's say, we have 3 documents :
An inverted index for these documents can be constructed as -
The terms in the dictionary are stored in a sorted order to find them quickly.
Searching multiple terms is done by performing a lookup on the terms in the index. It performs either UNION or INTERSECTION on them and fetches relevant matching documents.
An ES Index is spanned across multiple shards, each document is routed to a shard in a round--robin fashion while indexing. We can customize which shard to route the document, and which shard search-requests are sent to.
ES Index is made of multiple Lucene indexes, which in turn, are made up of index segments. These are write once, read many types of indices, i.e the index files Lucene writes are immutable (except for deletions).
Analysis is the process of converting text into tokens or terms which are added to the inverted index for searching. Analysis is performed by an analyzer. An analyzer can be either a built-in or a custom.
We can define single analyzer for both indexing & searching, or a different search-analyzer and an index-analyzer for a mapping.
Building blocks of analyzer-
1. Standard -
Divides text into terms on word boundaries. Lower-cases all terms. Removes punctuation and stopwords (if specified, default = None).
Text: The 2 QUICK Brown-Foxes jumped over the lazy dog's bone.
Output: [the, 2, quick, brown, foxes, jumped, over, the, lazy, dog’s, bone]
2. Simple/Lowercase -
Divides text into terms whenever it encounters a non-letter character. Lower-cases all terms.
Text: The 2 QUICK Brown-Foxes jumped over the lazy dog's bone.
Output: [ the, quick, brown, foxes, jumped, over, the, lazy, dog, s, bone ]
3. Whitespace -
Divides text into terms whenever it encounters a white-space character.
Text: The 2 QUICK Brown-Foxes jumped over the lazy dog's bone.
Output: [ The, 2, QUICK, Brown-Foxes, jumped, over, the, lazy, dog's, bone.]
4. Stopword -
Same as simple-analyzer with stop word removal by default.
Text: The 2 QUICK Brown-Foxes jumped over the lazy dog's bone.
Output: [ quick, brown, foxes, jumped, over, lazy, dog, s, bone]
5. Keyword / NOOP -
Returns the entire input string as it is.
Text: The 2 QUICK Brown-Foxes jumped over the lazy dog's bone.
Output: [The 2 QUICK Brown-Foxes jumped over the lazy dog's bone.]
1. Standard -
Divides text into terms on word boundaries, removes most punctuation.
2. Letter -
Divides text into terms whenever it encounters a non-letter character.
3. Lowercase -
Letter tokenizer which lowercases all tokens.
4. Whitespace -
Divides text into terms whenever it encounters any white-space character.
5. UAX-URL-EMAIL -
Standard tokenizer which recognizes URLs and email addresses as single tokens.
6. N-Gram -
Divides text into terms when it encounters anything from a list of specified characters (e.g. whitespace or punctuation), and returns n-grams of each word: a sliding window of continuous letters, e.g. quick → [qu, ui, ic, ck, qui, quic, quick, uic, uick, ick].
7. Edge-N-Gram -
It is similar to N-Gram tokenizer with n-grams anchored to the start of the word (prefix- based NGrams). e.g. quick → [q, qu, qui, quic, quick].
8. Keyword -
Emits exact same text as a single term.
Analyzers if not made right, can increase your search time extensively.
Avoid using regular expressions in queries as much as possible. Let your analyzers handle them.
ES provides multiple tokenizers (standard, whitespace, ngram, edge-ngram, etc) which can be directly used, or you can create your own tokenizer.
A simple use-case where we had to search for a user who either has “brad” in their name or “brad_pitt” in their email (substring based search), one would simply go and write a regex for this query, if no proper analyzers are written for this mapping.
CODE: https://gist.github.com/velotiotech/dc57ba572a0c882d060017f9271dca5b.js
This took 16s for us to fetch 1 lakh out of 60 million documents
Instead, we created an n-gram analyzer with lower-case filter which would generate all relevant tokens while indexing.
The above regex query was updated to -
CODE: https://gist.github.com/velotiotech/1285cc010dfa6999f6fc60208b62d94c.js
This took 109ms for us to fetch 1 lakh out of 60 million documents
Thus, previous search query which took more than 10-25s got reduced to less than 800-900ms to fetch the same set of records.
Had the use-case been to search results where name starts with “brad” or email starts with “brad_pitt” (prefix based search), it is better to go for edge-n-gram analyzer or suggesters.
Use Filter queries whenever possible.
ES usually scores documents and returns them in sorted order as per their scores. This may take a hit on performance if scoring of documents is not relevant to our use-case. In such scenarios, use “filter” queries which give boolean scores to documents.
CODE: https://gist.github.com/velotiotech/1968a9c9f3195a8b03f83617b1eb43fa.js
Above query can now be written as -
CODE: https://gist.github.com/velotiotech/ca4b5a33981141998f4d7a9b6b92cde0.js
This will reduce query-time by a few milliseconds.
Before creating any mappings, know your use-case well.
ES does not allow us to alter existing mappings unlike “ALTER” command in relational databases, although we can keep adding new mappings to the index.
The only way to change existing mappings is by creating a new index, re-indexing existing documents and aliasing the new-index with required name with ZERO downtime on production. Note - This process can take days if you have millions of records to re-index.
To re-index faster, we can change a few settings -
1. Disable swapping - Since no requests will be directed to the new index till indexing is done, we can safely disable swap.
Command for Linux machines -
CODE: https://gist.github.com/velotiotech/deade6e5af7312eda1b97216baf1603c.js
2. Disable refresh_interval for ES - Default refresh_interval is 1s which can safely be disabled while documents are getting re-indexed.
3. Change bulk size while indexing - ES usually indexes documents in chunks of size 1k. It is preferred to increase this default size to approx 5 to 10K, although we need to find the sweet spot while reindexing to avoid load on current index.
4. Reset replica count to 0 - ES creates at least 1 replica per shard, by default. We can set this to 0 while indexing & reset it to required value post indexing.
ElasticSearch is a very powerful database for text-based searches. The Elastic ecosystem is widely used for reporting, alerting, machine learning, etc. This article just gives an overview of ElasticSearch mappings and how creating relevant mappings can improve your query performance & accuracy. Giving right mappings, right resources to your ElasticSearch cluster can do wonders.
